F90 Yamaha 4 Stroke

The next-generation F90 is a direct-evolution of the previous 1.5 litre model, delivering increased fuel-efficiency, reduced-weight and improved performance. Filling an important place in Yamaha’s class-leading mid-range line-up, the new F90 delivers the perfect power option for the large number of Aussie built boats that have a maximum hull rating of 90 horsepower. The four-cylinder, 16-valve, SOHC 1.8L marine engine, is not only 10KGs lighter, but an increase in displacement over the previous generation 1.5L engine aids in a richer torque-band.

The reduction in weight and improved compactness has been achieved through the adoption of a single overhead camshaft valve-train, delivers smooth and efficient performance only seen in 16-valve, four-cylinder engines of this size. The new F90 delivers a 10% improvement in fuel-efficiency and a significant reduction in noise, through improved engine unit rigidity, muffler redesign and the addition of an intake silencer. The Yamaha F90 is compatible with Yamaha’s range of Command-Link gauges, while its NMEA2000 compatibility allows for easy integration with third-party multi-function displays, GPS and fish finders.

TECHNICAL SPECIFICATIONS

• Engine Type: 4-Stroke, 16 Valve DOHC Direct Action In-line 4
• Bore x Stroke (mm): 81.0 x 88.9
• Displacement (cc)1832.0
• Recommended Maximum RPM: 5300-6300
• Fuel Management: EFI
• Ignition: TCI
• Lubrication System: Wet-sump
• Alternator Output: 12V - 35A with Rectifier Regulator
• Gear Ratio2.15 : 1 (Counter Rotating Prop Available)
• Starter System: Electric
• Operation Method: Mechanical control (Optional Multifunction Tiller)
• Trim and Tilt Method: Power Trim & Tilt
• Digital Gauges: Optional
• Command Link Gauges: Optional

• Transom Height (mm [inch])L: 516 [20.3] | X 643 [25.3]
• Dry Weight (kg)L: 162 | X: 166
